NPort 6000 Series Log, Monitoring and Warning
11-2
System Log Settings
System Log Settings allow NPort users to customize network events that are logged by the NPort 6000. Events
are grouped into four categories, known as event groups, and the user selects which groups to log under either
the Local Log or Remote Log server. The actual system events that would be logged for each system group
are listed under the column “Summary”. For example, if System was enabled, then System Cold Start events
and System Warm Start events would be logged.
Local Log Keep the log in the flash of NPort 6000 up to 512 items.
Remote Log Keep the log in the remote defined Log Server.
You will need to assign a remote Log Server in the System Management /
Misc.
Network Settings / Remote Log Settings if remote log is checked.
System
System Cold Start NPort 6000 cold start.
System Warm Start NPort 6000 warm start.
Network
DHCP/BOOTP/PPPoE Get
IP/Renew
IP of the NPort 6000 is refreshed.
NTP Time synchronization successful.
NTP Connect Fail The NPot 6000 failed to connect to the NTP Server.
Mail Fail Failed to deliver the email.
IP Conflict There is an IP conflict on the local network.
Network Link Down LAN 1 Link is down.
Config
Login Fail
IP Changed Static IP address was changed.
Password Changed Administrator Password was changed.
Config Changed The NPort 6000’s configuration was changed.
Firmware Upgrade Firmware was upgraded.
SSL Certificate Import SSL Certificate was impoted.
Config Import Config was impoted.
Config Export Config was expoted.

Moxa Technologies NPORT 6150 Specifications

General

Display	-
Baud rate	921.6 Kbit/s
Data bits	5, 6, 7, 8
Isolation	1.5 kV
Stop bits	1, 1.5, 2
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow Control type	RTS/CTS, XON/XOFF
Flow control support	Yes
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Mean time between failures (MTBF)	2097705 h
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Built-in processor	No
Input voltage	12 - 48 V
Power consumption	285 mA
Power source type	DC
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, ARP, PPPoE
Security algorithms	AES, DES, SSH, SSL/TLS
Product color	Black, Blue, Grey
Housing material	Metal
Sustainability certificates	RoHS

Weight and Dimensions

Weight	700 g
Dimensions (WxDxH)	67 x 100.4 x 29 mm
