Moxa Technologies NPORT 6150 User Manual

NPort 6000 Series Getting Started
2-4
Panel, DIN-Rail, and Rack-Mounting
Wall or Cabinet Mounting
The NPort 6150, 6250, and 6450 device servers have built
-
in “ears” for attaching the device
server to a wall or the inside of a cabinet. We suggest using two screws per ear to attach the
device servers to a wall or the inside of a cabinet. The heads of the screws should be less than
6.0 mm in diameter, and the shafts should be less than 3.5 mm in diameter, as shown in the
figure at the right.
NPort 6150 NPort 6250 NPort 6450
DIN-Rail Mounting
DIN-rail attachments can be purchased separately to attach the NPort 6150, 6250, and 6450 to a DIN-rail.
When snapping the attachments to the DIN-rail, make sure that the stiff metal springs are at the top.
NPort 6150 NPort 6250 NPort 6450
Rack-Mounting
Use four screws to attach the NPort 6610/6650 to a standard rack.
NPort 6610/6650

Moxa Technologies NPORT 6150 Specifications

General

Display	-
Baud rate	921.6 Kbit/s
Data bits	5, 6, 7, 8
Isolation	1.5 kV
Stop bits	1, 1.5, 2
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow Control type	RTS/CTS, XON/XOFF
Flow control support	Yes
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Mean time between failures (MTBF)	2097705 h
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Built-in processor	No
Input voltage	12 - 48 V
Power consumption	285 mA
Power source type	DC
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, ARP, PPPoE
Security algorithms	AES, DES, SSH, SSL/TLS
Product color	Black, Blue, Grey
Housing material	Metal
Sustainability certificates	RoHS

Weight and Dimensions

Weight	700 g
Dimensions (WxDxH)	67 x 100.4 x 29 mm
