Moxa Technologies NPORT 6150 User Manual

NPort 6000 Series Configuring Serial Port Operation Modes
7-26
Username: This is the dial-out user ID account.
Password: This is the dial-out user password.
Authentication type (default=None): This field allows you to configure the method used, if any, to verify a
user’s ID and authorization.
Option Description
Local Verify the ID against the NPort 6000 User Table.
RADIUS Verify the ID against the external RADIUS server.
RADIUS-Local Radius authentication is tried first, switching to Local if unsuccessful.
Local-RADIUS Authentication is performed locally first, switching to Radius if unsuccessful
TACACS+ Verify the ID against the external TACACS+ server.
TACACS+-Local TACACS+ authentication is tried first, switching to Local if unsuccessful.
Local-TACACS+ Authentication is performed locally first, switching to Radius if unsuccessful
None Authentication is not required.
Try next type on authentication denied (default=Disable): The field enables or disables the system to try
next type on first authentication denied.
Disconnect by (default=None): If this field is set as DCD-off, the connection will be disconnected when the
DCD signal is off. If this field is set as DSR-off, the connection will be disconnected when the DSR signal is off.
PPPD Mode
PPPD (PPP on demand) is used for dial-in services, since it provides PPP services only when receiving a request
from a remote PC.
Destination IP address: This is the IP address of the remote dial-in/ dial-out server.
Source IP address: The Source IP address is IP address assigned to this serial port.
IP netmask: The IP netmask defines the netmask, also known as the subnet mask, for the PPP connection
TCP/IP compression (default=Disable): The setting of this field depends on whether the remote user’s
application requests compression.
Inactivity time (default=0 ms): This field specifies the idle time setting for auto-disconnection. A setting of 0
ms will cause the port to remain connected even if idle.
Link quality report (default=Disable): Setting this field to Enable allows the NPort 6000 to disconnect a
connection if the link noise exceeds a certain threshold.
Username: This is the dial-out user ID account.
Password: This is the dial-out user password.
Authentication type (default=None): This field allows you to configure the method used, if any, to verify a
user’s ID and authorization.

Moxa Technologies NPORT 6150 Specifications

General

Display	-
Baud rate	921.6 Kbit/s
Data bits	5, 6, 7, 8
Isolation	1.5 kV
Stop bits	1, 1.5, 2
RS-232 signals	CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx
RS-422 signals	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signals	Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-
Flow Control type	RTS/CTS, XON/XOFF
Flow control support	Yes
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Mean time between failures (MTBF)	2097705 h
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Built-in processor	No
Input voltage	12 - 48 V
Power consumption	285 mA
Power source type	DC
Storage temperature (T-T)	-40 - 75 °C
Maximum operating altitude	2000 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1/V2c/V3, HTTP, SMTP, ARP, PPPoE
Security algorithms	AES, DES, SSH, SSL/TLS
Product color	Black, Blue, Grey
Housing material	Metal
Sustainability certificates	RoHS

Weight and Dimensions

Weight	700 g
Dimensions (WxDxH)	67 x 100.4 x 29 mm
