NPort 6000 Series Log, Monitoring and Warning
DSR changed
A change in the DSR (Data Set Ready) signal indicates that the data communication equipment is powered off.
For example, if the DSR signal changes to low, it indicates that the data communication equipment is powered
off. When the DSR signal changes to low, the NPort 6000 will automatically send a warning to the administrator
as configured on the Serial Event Settings page.
For the NPort 6450 and 6650, after the relay output status has been changed, administrators may reset its
status by selecting Acknowledge Event from the NPort 6000 console, or by correcting the DSR signal. Please
refer to the section on System Monitoring later in this chapter for more information.
ATTENTION
SNMP indicates a change in DCD or DSR signals but does not differentiate between the two. A change in either
signal from “
–” to “+” is indicated by “link up,”, and a change in either signal from “+” to “–
” is indicated by
“link down.”
Email Alert
The Email Alert settings configure how email warnings are sent for system and serial port events. You may
configure up to four email addresses to receive automatic warnings.
ATTENTION
Consult your Network Administrator or ISP for the proper mail server settings. The Auto warning function may
not work properly if it is not configured correctly. The NPort 6000’s SMTP AUTH supports LOGIN, PLAIN, and
CRAM
-MD5 (RFC 2554).
Mail server: This field is for your mail server’s domain name or IP address.
Username: This field is for your mail server’s username, if required.
Password: This field is for your mail server’s password, if required.
From email address: This is the email address from which automatic email warnings will be sent.
To email address 1 to 4: This is the email address or addresses to which the automatic email warnings will be
sent.
