OnCell G3100 Series Using the Web Console
The OnCell G3100’s web console will appear.
ATTENTION
In the Overview page you will find general information about the device such as firmware version, IP address
and signal RSSI. In particular, the RSSI value displayed here can be mapped to the dBm value specific to the
cellular module used for the OnCell:
RSSI dBm RSSI dBm
0 -113 dBm or less 16 -81 dBm
1 -111 dBm 17 -79 dBm
2 -109 dBm 18 -77 dBm
3 -107 dBm 19 -75 dBm
4 -105 dBm 20 -73 dBm
5 -103 dBm 21 -71 dBm
6 -101 dBm 22 -69 dBm
7 -99 dBm 23 -67 dBm
8 -97 dBm 24 -65 dBm
9 -95 dBm 25 -63 dBm
10 -93 dBm 26 -61 dBm
11 -91 dBm 27 -59 dBm
12 -89 dBm 28 -57 dBm
13 -87 dBm 29 -55 dBm
14 -85 dBm 30 -53 dBm
15 -83 dBm 31 -51 dBm or greater
Web Console Navigation
The left panel of the OnCell G3100’s web console is the navigation panel, and contains an expandable menu
tree for navigating among the various settings and categories. When you click on a menu item in the navigation
panel, the main window will display the corresponding options for that item. Configuration changes can then be
made in the main window. For example, if you click on Basic Settings in the navigation panel, the main
window will show a page of basic settings that you can configure.
You must click on the Submit button to keep your configuration changes. The Submit button will be located
at the bottom of every page that has configurable settings. If you navigate to another page without clicking the
Submit button, your settings will not be retained.
Changes will not take effect until they are saved and the OnCell is restarted! You may complete this in
one step by clicking on the Save/Restart option after you submit a change. If you need to make several
changes before restarting, you may save your changes without restarting by selecting Save Configuration in
the navigation panel. If you restart the OnCell G3100 without saving your configuration, the OnCell G3100 will
discard all submitted changes.
