OnCell G3100 Series Initial IP Address Configuration
ATTENTION
In order to use
the ARP setup method, both your computer and the OnCell G3100
must be connected to the
same LAN.
You may use an Ethernet cable to connect the OnCell G3100 directly to your computer’
Before executing the ARP command, your OnCell G3100 must be configured with the factory
default IP
address (192.168.12
7.254) and your computer and the OnCell G3100 must be on the same subnet. In
addition, note that ARP command must be issued within 3 minutes after the OnCell is turned. After 3 minutes
have elapsed, the OnCell will no longer accept ARP commands.
To use ARP to configure the IP address, complete the following:
1. Obtain a valid IP address for your OnCell G3100 from your network administrator.
2. Obtain your OnCell G3100’s MAC address from the label on the bottom panel.
3. Execute the
arp -s command from your computer’s MS-DOS prompt as follows:
arp -s <IP address> <MAC address>
For example,
C:\> arp -s 192.168.200.100 00-90-E8-04-00-11
4. Next, execute a special Telnet command by entering the following exactly:
telnet 192.168.200.100 6000
When you enter this command, a Connect failed message will appear, as shown below.
5. After the OnCell G3100 reboots, its IP address will be assigned to the new address and you can reconnect
using Telnet to verify that the update was successful.
Telnet Console
Depending on how your computer and network are configured, you may find it convenient to use network
access to set up your OnCell G3100’s IP address. This can be done using Telnet.
ATTENTION
Figures in this section were taken from
the OnCell G3100’s Telnet console.
