Use and warning instructions in compliance with EC regulations - Page 44
POS. DESCRIPTION
9
Red mushroom emergency pushbutton with mechanical latch.
Operating this pushbutton stops all movements and the vehicle engine (if applicable). The engine can only be started back up
again when the button is released.
N.B.: Avoid using this device just to stop the engine.
10
Proportional Control for movement speed adjustment
Push the lever upward to increase the speed of the movements.
N.B.: to obtain any movement, you always need to activate the speed adjustment proportional control. The lever
automatically goes back to its resting position.
11
Green indicator. Authorisation indicator for outriggers resting on the ground.
When this indicator is on, it means that it is possible to manoeuvre the boom.
12
Green indicator. Machine status signalling.
It indicates that the ascent/descent movement of the main boom is enabled
13
Green indicator. Machine status signalling.
It indicates that the telescopic function of the main boom is enabled
14
Optional. Red indicator. Danger signal.
When the indicator is on, it means thatthe door has not been closed correctly. No movement is allowed when this
indicator is on. The door must be properly closed to resume movements.
15
Optional. Red indicator. Danger signal.
When this indicator is on, it means that the maximum weight that can be loaded in the cage has been reached. No
movement is allowed when this indicator is on.
16
Red indicator. Danger signal.
When the indicator is on, it means that the vehicle gradient is greater than the allowed limits. Fold the platform and redo the
outrigging operations. In order to outrig the vehicle, see paragraph “OUTRIGGING”.
17
Red indicator. Danger signal.
When the red indicator is turned on it means that the maximum boom extension has been reached. When this indicator is on,
the movements that increase the platform boom are not allowed.
18
Hour meter
19
Optional. Outriggers simultaneous drive.
Pulling the lever downwards starts the automatic outrigging according to the position of the POS 20 and POS 21 selectors. You
need to hold the button down until the vehicle stops its upward movement and the green consent indicator comes on.
Pushing the lever upwards closes the outriggers. The button must be kept pressed until complete retraction of the crosspieces.
20
Optional. Duplication of the configuration selector of the left side outriggers.
21
Optional. Duplication of the configuration selector of the right side outriggers.
22
Optional.
Cage manual levelling control.
23
Optional.
Set-up for control/luminous indicator. If present, see the annex "OPTIONS" in the "ANNEX" section.
24
Optional.
Set-up for control/luminous indicator. If present, see the annex "OPTIONS" in the "ANNEX" section.
