4-4 System Configuration
Description of On-Screen Items and Key Usage
Use the following keyboard keys to work with the SETUP utility. (Key functions are also listed at
the bottom of the screen.)
Shows the current menu.
Options to be
configured
Online help
window
Denotes there are
submenus
Parameters (selected parameters are
highlighted)
Explanation of keys
Cursor (n, p):
Selects an item on the screen. The highlighted item is currently
selected.
Cursor (m, o):
Selects the Main, Advanced, Security, System Hardware, Boot, or
Exit menu.
–
+
Changes the value (parameter) of the selected item to the
previous value.
Changes the value (parameter) of the selected item to next value.
Enter
Displays a submenu or chooses the selected parameter.
Esc
Displays the previous screen.
F1:
Press F1 when you need help on SETUP operations. The help
screen for SETUP operations appears. Press Esc to return to the
previous screen.
F9:
Shows the following:
Setup Confirmation
Load default configuration now?
[Yes] [No]
ᴾ
If you select “Yes” and then press the Enter key, all items in the
setup are set to default values. If you select “No” and then press
either the
Enter or Esc key, the status before pressing the F9
key is restored.
ᴾ
ᴾ
ᴾ
