4-46 System Configuration
Setting a Management PC
The following provides management PC considerations to connect the server and a management
PC.
Setting Your Browser
Configure the following.
- Enable SSL.
Supported browsers
The following browsers are supported.
- Microsoft Internet Explorer 6.0
- Netscape 7.0
- Mozilla 1.6
Java2 Runtime Environment
Java2 Runtime Environment, Standard Edition 1.4.2_04 or later is required.
Follow the steps below if you use NEC EXPRESSBUILDER for installation:
z When the OS of the management PC is Windows:
(1) Activate Windows on the PC on which you want to install Java2 Runtime Environment
and set the “NEC EXPRESSBUILDER” CD-ROM.
(2) By the auto startup function, the master control menu of NEC EXPRESSBUILDER
appears. Click “Software Setup” and then “NEC DianaScope,” and then run the installer
of JRE, which you find in the NEC DianaScope install menu.
z When the OS of the management PC is Linux:
The JRE installer (Linux) is stored in the following directory of the NEC EXPRESSBUILDER
CD-ROM:
/dianascope/jre_x
For installing JRE, log on as root user or obtain the root authority by the su command.
(1) Copy the JRE installer to any directory. Below is an example of copying the installer from
the NEC EXPRESSBUILDER to /user/local/bin:
cp /mnt/cdrom/dianascope/jre_x/j2re-1_4_2_09-linux-i586.rpm.bin/usr/
local/bin
(2) Go to the directory where you copied the JRE installer. Below is an example that the
installer was copied to /user/local/bin:
cd /user/local/bin
