NEC Express5800 Series User Manual

System Upgrade 8-37
5. Gently insert the slot on the board against the
connecting part of the board㪅㩷
PCI board
6.
Insert the board for connecting part of the board to securely connect to the slot.
IMPORTANT:
If you have trouble installing the board, remove the board once and install it again. Be
careful since the board gets damaged if you press it too hard.
7. Install the PCI bracket and secure the board㪅㩷
8.
Install CPU/IO module referring to the page 8-19.
9. Turn ON the power by pressing the POWER switch of installed CPU/IO module.
Removing PCI Board
Removal of PCI board card follows the reverse procedure of the installation and installs the expansion
slot cover.
