NEC Express5800 Series User Manual

2-22 General Description
LEDs
This section describes indications and meanings of the LEDs on NEC Express5800/ft series.
See “NAMES AND FUNCTIONS OF COMPONENTS” (pages 2-6 through 2-17) for the locations
of each LED.
POWER LED
This LED illuminates in green while the server is powered on. When power is off, this LED does
not illuminate. The LED also illuminates in green when one of CPU/IO modules is powered on.
DISK ACCESS LED
This LED indicates the status of hard disk drives loaded on 3.5-inch disk bays. Whenever the hard
disk drives are accessed, the LED blinks in green.
When this LED illuminates in amber, it indicates a hard disk drive has a problem. You can see the
status of the failed hard disk drive by checking the LED of each hard disk drive.
If this LED is blinking in amber, it indicates volumes in hard disk drives are not mirrored. See
“HARD DISK CONFIGURATIONS THAT CAN BE BUILT ON THE NEC Express5800/ft series”
(page 3-2) to configure mirror volumes.

NEC Express5800 Series Specifications

General

Series	Express5800
Category	Server
Processor	Intel Xeon processors
Network	Gigabit Ethernet, 10 Gigabit Ethernet (Varies by model)
Operating System Support	Windows Server, Linux variants
Form Factor	Tower, Rackmount (1U, 2U, etc. - varies by model)
Memory	DDR4 ECC DIMM (Capacity varies by model)
Storage	SAS/SATA HDD/SSD, NVMe SSD (Configuration varies by model)
