System Configuration 4-41
HOW TO CLEAR PASSWORDS
1. Power off NEC Express5800/ft series and unplug the both power cords.
2. Remove the both CPU/IO modules (#1 and #2) from the NEC Express5800/ft series (see
“Removing CPU/IO Module” on page 8-17).
3. Make setting of jumper switch for clearing the password of CPU/IO module # 0...
Remove the clips from the jumper pins 11-12 on CPU/IO module # 0 and place them on
the jumper pins 3-4 on the CPU/IO Module #1.
4. Mount the CPU/IO Module # 0 to NEC Express5800/ft series (see “Installing CPU/IO
Module” on page 8-19).
5. Connect the power cord of CPU/IO module #0 only, and then press the POWER switch to
power on.
6. When you see “8151: Password Cleared By Jumper” and “Press <F1> to resume, <F2> to
Setup” during POST after the startup, press the POWER switch to power off, and then
disconnect the power cord from the outlet.
Example
-------------------------------------------------------------------------------------------------
Phoenix ServerBIOS 3 Release 6.0
Copyright 1985-2003 Phoenix Technologies Ltd.
All Rights Reserved
GPJ1. HA. XXXX. X. XXXXXXXXXX
IGPJ BIOS Release X. X
Build Time : XX/XX/XX XX : XX : XX
2x Intel (R) Xeon (R) CPU 3.60GHz
3072M System RAM Passed
2048K Cache SRAM Passed
System BIOS shadowed
Video BIOS shadowed
IPMI Base Board Management Controller was detected.
Device ID : XX Device Revision : XX
IPMI Version : X. X Firmware Revision : XX. XX
Self Test Result : XXXXH
SMBIOS Initialize. . . . . . . . . Passed
System Monitoring Check. Passed
ERROR
8151: NVRAM Cleared By Jumper
Press <F1> to resume, <F2> to Setup
--------------------------------------------------------------------------------------------------
7. By referring to “Removing CPU/IO Module” on page 8-17, remove the CPU/IO module
#0 from the server.
8. Reset the jumper switch setting.
Remove the clips from the jumper pins 3-4 and place them on the jumper pins 11-12 on
the CPU/IO Module # 0.
9. Clear password for the CPU/IO module #1 by following the steps 3 to 8.
