NEC Express5800 Series User Manual

8-32 System Upgrade
Installing ft Remote Management Card
Follow the procedures below and install ft Remote Management Card.
1. Remove CPU/IO module referring page 8-17.
TIPS:
If PCI board is already installed to the CPU/IO module, remove the PCI board referring to
page 8-37.
2. Remove PCI rear bracket installed to the CPU/IO
module as a standard with two screws.
PCI rear bracket
3. Remove the blank cover for LAN connector of ft Remote
Management Card. Grab the top and bottom of the blank
cover to unlock and remove it.
Blank cover for
LAN connector
4. Install ft Remote Management Card to PCI rear bracket
with one screw.
ft Remote
Management
Card
