NEC Express5800 Series - CPU;IO Module

2-18 General Description
CPU/IO Module
1) Module handle
2) Cooling fan unit 1
3) Heat sink (CPU#1)
4) PCI slot
5) DIMM
For more information on slot
numbers, see the figure on next
page.
C
C
P
CPU/IO module (without a water-cooling kit)
(320Fa-L/320FaLR model)
