4-40 System Configuration
Example
-------------------------------------------------------------------------------------------------
Phoenix ServerBIOS 3 Release 6.0
Copyright 1985-2003 Phoenix Technologies Ltd.
All Rights Reserved
GPJ1. HA. XXXX. X. XXXXXXXXXX
IGPJ BIOS Release X. X
Build Time: XX/XX/XX XX : XX : XX
2x Intel (R) Xeon (R) CPU 3.60GHz
3072M System RAM Passed
2048K Cache SRAM Passed
System BIOS shadowed
Video BIOS shadowed
IPMI Base Board Management Controller was detected.
Device ID : XX Device Revision : XX
IPMI Version : X. X Firmware Revision : XX. XX
Self Test Result : XXXXH
SMBIOS Initialize. . . . . . . . . Passed
System Monitoring Check. Passed
ERROR
8150: NVRAM Cleared By Jumper
Press <F1> to resume, <F2> to Setup
-------------------------------------------------------------------------------------------------
ᴾ
7. By referring to “Removing CPU/IO Module” on page 8-17, remove the CPU/IO module
#0 from the server.
8. Restore the previous CMOS clear jumper switch settings. Remove the jumper pins 1-2 of
the CPU/IO module #0 and install them on the jumper pins 7-8.
9. By referring to “Installing CPU/IO Module” on page 8-19, install the CPU/IO module #0
on the server.
10. Reconnect the power cord of the CPU/IO module #0 and press the POWER switch to
power on.
11. After the startup, press the F2 key during POST to start BIOS SETUP.
12. Make settings in SETUP as you desire and then the settings by selecting “Exit”ĺ “Exit
Saving Changes.” Switch the power off and disconnect the power cord from the outlet.
13. Clear CMOS for the CPU/IO module #1 by following the steps 3 to 12.
14. By referring to “Installing CPU/IO Module” on page 8-19, install both CPU/IO modules
on the server.
15. Connect both power cords.
