Maintenance 6-9
Guideline
Shows the details of the keys to operate window.
Test summary window
Shows the results of each test that executed the diagnostics. Move the cursor and press the
Enter key on the cursor line to display the details of the test.
When an error is detected by the system diagnostics, the relevant test result in the test
summary window is highlighted in red, and “Abnormal End” is displayed in the result on
the right side.
Move the cursor to the test that detected the error, and press the Enter key. Record the
error message that has been output to the Detail Information screen and contact your sales
agent.
7. Follow the guideline shown at the bottom of the screen, and press the Esc key.
The [Enduser Menu] below is displayed.
<Test Result>
Shows the diagnostics completion screen of the above diagnostics.
<Device List>
Shows a list of connected devices.
<Log Info>
Shows the log information of the diagnostics. It can be saved on a floppy disk. To save it
on a floppy disk, insert a formatted floppy disk to the floppy disk drive, and select
<Save(F)>.
<Option>
Changes the output destination of a log.
<Reboot>
Reboots the system. 㩷
㩷
8. Select <Reboot> in the [Enduser Menu] above.
The server restarts and the system is started from the NEC EXPRESSBUILDER.
9. Exit the NEC EXPRESSBUILDER, and remove the CD-ROM from the CD-ROM drive.
