NETGEAR GS752TP User Manual

Configuring Switching Information
100
GS752TP, GS728TP, and GS728TPP Gigabit Smart Switches
MST Configuration
Use the MST Configuration screen to configure Multiple Spanning Tree (MST) on the switch.
 To configure an MST instance:
1. Select Switching
 STP  Advanced  MST Configuration.
The following screen displays:
2. To add an MST instance, configure the MST values and click Add:
• MST ID. Specify the ID of the MST to create. The valid range is 1–15.
• Priority. Specify the bridge priority value for the MST. When switches or bridges are
running STP, each is assigned a priority. After exchanging BPDUs, the switch with the
lowest priority value becomes the root bridge. The bridge priority is a multiple of 4096.
If you specify a priority that is not a multiple of 4096, the priority is automatically set to
the next lowest priority that is a multiple of 4096. For example, if you set the priority to
any value from 0 through 4095, the priority is set to 0. The default priority is
32768.The valid range is 0–61440.
• VLAN ID.
The list contains all VLANs configured on the switch. Select a VLAN to
associate with the MST instance.
3. Click APPLY to send the updated configuration to the switch.
Fast Link Indicates whether the port is enabled as an edge port.
Status
The forwarding state of this port.
Field Description

NETGEAR GS752TP Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Number of multicast groups filtered	1024
Fiber optic connector	SFP
SFP module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
MAC address table	8000 entries
Packet buffer memory	8 MB
Number of static routes	32
Supported network protocols	IPv4, IPv6, TFTP, SNTP, TACACS+
Power consumption (typical)	384 W
Safety	CE, CSA, UL
Product color	Gray
Electromagnetic compatibility	CE, FCC, Class A EN 55022, Class A C-Tick, EN 50082-1, EN 55024, CCC
Mean time between failures (MTBF)	220447 h
Heat dissipation	1750.70 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	15.4 W
Power over Ethernet plus (PoE+) ports quantity	8
Cables included	AC

Weight and Dimensions

Depth	316 mm
Width	440 mm
Height	43 mm
Weight	5100 g
