NETGEAR GS752TP User Manual

Managing Device Security
198
GS752TP, GS728TP, and GS728TPP Gigabit Smart Switches
IP Rules
Use the IP Rules screen to define rules for IP-based standard ACLs. The access list
definition includes rules that specify whether traffic matching the criteria is forwarded
normally or discarded.
Note: There is an implicit “deny all” rule at the end of an ACL list. This rule
means that if an ACL is applied to a packet and if none of the explicit
rules match, the final implicit “deny all” rule applies and the packet is
dropped.
 To configure IP rules, select the following:
1. Select Security
 ACL > Advanced  IP Rules.
In the following screen, an IP rule exists, and one rule has been configured.
2. From the ACL ID field, select the IP ACL for which to create or update a rule.
The valid range is 1–99.
3. Configure the following fields:
• Rule ID. Specify a number from 1 to 10 to identify the IP
ACL rule. Y
ou can create up
to ten rules for each ACL.
• Action. Select an ACL forwarding action:
• Permit. Forwards packets which meet the ACL criteria.
• Deny. Drops packets which meet the ACL criteria.

NETGEAR GS752TP Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Number of multicast groups filtered	1024
Fiber optic connector	SFP
SFP module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
MAC address table	8000 entries
Packet buffer memory	8 MB
Number of static routes	32
Supported network protocols	IPv4, IPv6, TFTP, SNTP, TACACS+
Power consumption (typical)	384 W
Safety	CE, CSA, UL
Product color	Gray
Electromagnetic compatibility	CE, FCC, Class A EN 55022, Class A C-Tick, EN 50082-1, EN 55024, CCC
Mean time between failures (MTBF)	220447 h
Heat dissipation	1750.70 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	15.4 W
Power over Ethernet plus (PoE+) ports quantity	8
Cables included	AC

Weight and Dimensions

Depth	316 mm
Width	440 mm
Height	43 mm
Weight	5100 g
