NETGEAR GS752TP User Manual

Managing Device Security
191
GS752TP, GS728TP, and GS728TPP Gigabit Smart Switches
4. In the Binding Configuration area, the Inbound only packet filtering direction for an ACL is
selected in the Direction field.
5. In the Port Selection T
able area, specify the list of all available valid interfaces for ACL
mapping.
All non-routing physical interfaces and interfaces participating in the LAG are listed.
6. To add a rule to the ACL, select the check box next to the ACL, then click ADD.
7. Click APPLY
to update the switch with the new settings.
Configuration changes take effect immediately.
MAC ACL
A MAC ACL consists of a set of rules that are matched sequentially against a packet. When a
packet meets the match criteria of a rule, the specified rule action (permit or deny) is taken
and the additional rules are not checked for a match.
The steps for defining a MAC ACL and applying it to the switch are described in the following
sections:
1. Use the MAC ACL screen to create the ACL ID.
2. Use the MAC Rules screen to create rules for the ACL.
3. Use the MAC Binding Configuration screen to assign the ACL by its ID number to a port.
4. Optionally
, use the
MAC Binding Table screen to view the configurations.
 To configure a MAC ACL:
1. Select Security
 ACL > Basic > MAC ACL.
Destination IPv6 L4
Port
• Destination L4 port (protocol). Specify the destination IPv6 L4 port protocol.
• Destination L4 port (value). Specify the destination IPv6 L4 port value.
Source IPv6 L4 Port • Source L4 port (protocol). Specify the source IPv6 L4 port protocol.
• Source L4 port (value). Specify the source IPv6 L4 port value.
ACL Based on Fields

NETGEAR GS752TP Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Number of multicast groups filtered	1024
Fiber optic connector	SFP
SFP module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
MAC address table	8000 entries
Packet buffer memory	8 MB
Number of static routes	32
Supported network protocols	IPv4, IPv6, TFTP, SNTP, TACACS+
Power consumption (typical)	384 W
Safety	CE, CSA, UL
Product color	Gray
Electromagnetic compatibility	CE, FCC, Class A EN 55022, Class A C-Tick, EN 50082-1, EN 55024, CCC
Mean time between failures (MTBF)	220447 h
Heat dissipation	1750.70 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	15.4 W
Power over Ethernet plus (PoE+) ports quantity	8
Cables included	AC

Weight and Dimensions

Depth	316 mm
Width	440 mm
Height	43 mm
Weight	5100 g
