NETGEAR GS752TP User Manual

Managing Device Security
168
GS752TP, GS728TP, and GS728TPP Gigabit Smart Switches
4. From the list in the 2 column, select the authentication method, if any, that must appear
second in the selected authentication login list.
Use this method if the first method times out.
If you select a method that does not time out as the second method, the third method is
not tried. This parameter does not appear when you first create a login list.
5. From the list in the 3 column, select the authentication method, if any, that must appear third
in the selected authentication login list.
This parameter does not appear when you first create a login list.
6. Click APPLY
to update the switch with the HTTP Authentication settings.
HTTPS Authentication List
Use the HTTPS Authentication List to configure the default HTTPS login list.
 To change the HTTPS authentication method for the default list:
1. Select Security
 Management Security Authentication List > HTTPS Authentication
List.
The following screen displays:
2. Select the check box next to the List name.
3. From the list in the 1 column, select the HTTPS authentication method that must appear first
in the selected authentication login list.
If you select a method that does not time out as the first method, such as local, no other
method is attempted, even if you have specified more than one method.
This parameter
does not appear when you first create a login list. User authentication occurs in the order
the methods are selected. Possible methods are as follows:

NETGEAR GS752TP Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Number of multicast groups filtered	1024
Fiber optic connector	SFP
SFP module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
10G support	-
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
DHCP features	DHCP client
MAC address table	8000 entries
Packet buffer memory	8 MB
Number of static routes	32
Supported network protocols	IPv4, IPv6, TFTP, SNTP, TACACS+
Power consumption (typical)	384 W
Safety	CE, CSA, UL
Product color	Gray
Electromagnetic compatibility	CE, FCC, Class A EN 55022, Class A C-Tick, EN 50082-1, EN 55024, CCC
Mean time between failures (MTBF)	220447 h
Heat dissipation	1750.70 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	15.4 W
Power over Ethernet plus (PoE+) ports quantity	8
Cables included	AC

Weight and Dimensions

Depth	316 mm
Width	440 mm
Height	43 mm
Weight	5100 g
