The BASIC Home page displays.
7. Select ADVANCED > Administration > Firmware Update.
The Firmware Update page displays.
8.
Locate and select the firmware file on your computer or mobile device:
a. Click the Browse button.
b.
Navigate to and select the firmware file.
The file ends in .img.
9. Click the Upload button.
A warning pop-up window displays.
10. Click the OK button.
WARNING: To avoid the risk of corrupting the firmware, do not interrupt the upload.
For example, do not close the browser, click a link, or load a new page. Do not turn
off the AP. Wait until the AP finishes restarting and the Power LED turns solid green.
A progress bar might show the progress of the firmware upload process. The firmware
upload process takes several minutes. When the upload is complete, your AP restarts.
To verify that the AP runs the new firmware version, continue with the following steps:
11.
Connect your computer or mobile device to the AP in one of the following ways
•
Connect directly to the AP’s WiFi network or LAN. (Applies to the AP in either
operation mode.)
•
Connect to the same network that the AP is connected to. (Applies only if the AP
is operating in AP mode.)
12.
Launch a web browser and enter http://www.routerlogin.net in the address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use routerlogin.net on page 32.
A login window displays.
If your browser displays a security warning, dismiss the warning. For more information,
see Dismiss a browser security warning on page 38.
13. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The BASIC Home page displays.
User Manual136Maintain and Monitor
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
