Table 8. WAX204 AP specifications (Continued)
DescriptionFeature
–4°F to 158°F (–20ºC to 70ºC)Storage temperature
5 to 95% maximum relative humidity, noncondensingStorage humidity
One 10/100/1000BASE-T Ethernet (RJ-45) port with Auto Uplink (Auto MDI-X)WAN (Internet)
Four 10/100/1000BASE-T Ethernet (RJ-45) ports with Auto Uplink (Auto MDI-X)LAN
IEEE 802.11ax
IEEE 802.11ac specification
IEEE 802.11n 2.0 specification
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
WiFi standards
2.4 GHz and 5 GHz, concurrent operationRadio bands
Up to 600 Mbps at 2.4 GHz
Up to 1200 Mbps at 5 GHz
Throughput can vary. Network conditions and environmental factors, including
volume of network traffic, building materials and construction, and network overhead,
affect the data throughput rate.
Maximum theoretical WiFi
throughput
The AP can support a maximum of 64 WiFi clients:
Maximum number of 2.4 GHz WiFi clients: 64
Maximum number of 5 GHz WiFi clients: 64
Even though each individual radio can support 64 clients, the total number of clients
that the AP can support is 64. (For example, 44 clients on the 2.4 GHz radio and 20
clients on the 5 GHz radio.)
In a WiFi network, the actual number of clients might be limited by the amount of
WiFi traffic that is generated by each client.
Maximum number of
supported clients
US: 2.412–2.462 GHz
Europe: 2.412–2.472 GHz
Australia: 2.412–2.472 GHz
Operating frequency range
2.4 GHz band
US: 5.180–5.240 + 5.745–5.825 GHz
Europe: 5.180–5.700 GHz
Australia: 5.180–5.320 + 5.500–5.825 GHz
Operating frequency range
5 GHz band
WPA2 Personal [AES]
WPA-Personal [TKIP] + WPA2-Personal [AES]
WPA/WPA2 Enterprise
WPA3- Personal
802.11 security
CE (EN60950)Safety Certification
User Manual247Factory Default Settings and
Technical Specifications
WiFi 6 AX1800 Dual Band Wireless Access Point WAX204
