DVR Server Manual
sensor forcibly. Press the button again to stop checking all the time, then
system checks sensor according to Sensor Setup. When there is an alarm, the
corresponding button will show the alarm with green.
Note:
When you select NV 7632 and the combination is not the standard
configuration (combination of NV 7608 and NV 7616 or NV 7608: total DI is
less than 32), some ports are not available according to the setting of decoder
address. For example: user selects NV 7632 and the combination is NV 7608
(decoder address is 1) and NV 7616 (decoder address is 2), then the DI ports
9 to 16 are not available, so that the status indication is not available.
2. DO Control
Press number to open/close alarm device relay switch manually. The
status of DO has two types:
Output channel 2 is close.
Output channel 1 is open.
When there is no alarm triggered out, user can press the number button to
output alarm forcibly and the button will show it with green. Press it again, the
output will be closed.
52
