DVR Server Manual
Note:
1) PTZ position will influence PTZ control. E.g.: if you set it as obverse
and press left, then it will turn left. If you set it as inverse and press left,
then it will turn right;
If there is (H) after the PTZ protocol, it has the high speed of Preset
function. If there is no (H), it only has ordinary functions;
The PTZ address will be sent as a message option. Take care that some
addresses begin from 0. That is to say，when the address number is 1, the real
address is 0. So we must set it according to their relations.
2.4.2 Motion Detection Relay
【DO Port】【DO Port Name】Select a DO port and set its name to identify
the various DO port. It will be shown as a tip when the mouse moves closely or
above the DO button in DVR Server or NVR Client.
【Camera Alarm Detected in】Select camera to be set from drop down
list.
【Alarm Write Log】Select write alarm log or not when there is an alarm
triggered. You can set the interval to write log as 5s, 10s, 30s, 1min, 2min or
3min to enable writing log when there is alarm triggered.
【Send Alarm to client】Select sending alarm to network clients or not.
【Motion Alarm Sound 】 Press button to select a “.wav” sound file
for a motion alarm. If there is a motion alarm, the sound file will be played. Also,
you can test it by pressing button.
【Video Loss Alarm Sound】Press
button to select a “.wav” sound
file for a video loss alarm. If there is a video loss alarm, the sound file will be
played. Also, you can test it by pressing
button.
【Trigger DO Output】Select which DO ports will be triggered by above
camera alarms.
【Motion Send Email】Set sending Email disable or enable when there is
mtion alarm triggered. You can set the interval to send an email as 5s, 10s, 30s,
1min, 2min or 3min to enable sending email.
68
