DVR Server Manual
to the network bandwidth.
【Image Size】Set the resolution for local record. There is an item
“704*576(12fps)”, each channel can be set “704*576”, but not real time,
system will select frame rate automatically around 12-15fps. To get best effect,
you should set the resolution of local record according to your CPU
configuration. There is a referenced configuration sample as below:
Computer configuration:
CPU: Intel Pentium 4 2.4GHz
Motherboard: ECS 848P-A
Graphic Card: ATI 9550 128MB,
Memory: 512MB
HDD: 120G (IDE)
Recommended resolution configuration for different channels:
DVR Board
Channels
Recommended
Resolution
Remark
64 CIF
Continuous
recording is not
recommended
48 CIF
DCIF
40
CIF
DCIF
32
CIF
DCIF
24
CIF
4CIF
DCIF
Less or Equal
to16
CIF
【OSD Date】Select whether display the OSD date on the screen or not.
When you select “Not”, the date will not display on the screen of corresponding
channel.
【Masking Bitmap File】Watermark function ,the logo picture must be
edited no more than 128*128 pixels file size, both the length and width should
be multiples of 16, and saved as bmp format.
【Stream Type】Select whether program record audio data or not. This
setting is not available for IP Cameras, for stream type of IP Camera; you
should set it remotely in IP Camera Setup.
61
