2-4
Once the ink is installed, the ink door must be completely closed and remain closed during
printing. Note that it takes the printer a few moments to return to the Printer Ready state after
the ink door has been open and closed.
Figure 2-1. Callisto Media Entrance Side
Callisto Printer Media Exit Side
Media exits the printer on its left side. Because the media path is short and simple, a vacuum
table is used to aid in holding the media in place. It is critical to make sure there are no
obstructions to the printer exit. The media must be allowed to flow freely from the printer and
not back up into the printer exit. If the media is allowed to back up into the printer exit, it may
hit and damage the printhead.
The 7-inch Touch Operator Panel allows the printer operator to interact with the printer. From
this panel you can jog media, check ink and other status, view printer reports and version
information, and even print jobs that have been stored on the printer. The Touch Operator
Panel displays the printer status, printer network address and current date and time. Further
details on this display are covered later in the User Guide.
