2-5
The blue LED power button at the printer front indicates that the printer is turned on. Press
this button to power the printer On/Off; the LED will blink during both printer bootup and
printer shutdown. When printing the LED will blink each time a gap or mark passes under the
printer sensor. [REPLACE PIC]
Figure 2-2. Callisto Media Exit Side
Callisto Printer Back Side
The back side of the Callisto printer contains the master power switch, the power port, and the
network port. The master power switch will generally remain on because for normal
operations the front power button will be accessed to turn the printer on/off. The Callisto
printer is a network printer; therefore, the network port will be needed. If you wish to printer
over USB, there are special USB-to-network adapters that are readily available.
The serial number of the printer can also be found on the back side of the printer. The serial
number is available through the printer operator panel as well by clicking on the “?” symbol in
the upper right corner of the display. All Callisto serial numbers begin with the letters CAL and
Media Exit with Vacuum Table
Gap/Mark Indicator
