8.7 Performance Testing

8-9 ZM2371/ZM2372

Measurement frequency 10kHz, Measurement signal level 1 Vrms, Cable length 0m

Measurement

range

Standard

(nominal

value)

Calibration value

of standard “A”

Measurement

value “B”

Difference

100×(B

A)/A

Specification

B-A

1M

10pF

C F

C %

C ± 0.83 %

D

D ± 0.0083

100k

100pF

C F

C %

C ± 0.29 %

D

D ± 0.0029

10k

1000pF

C F

C %

C ± 0.19 %

D

D ± 0.0019

1k

0.01µF

C F

C %

C ± 0.18 %

D

D ± 0.0018

100

0.1µF

C F

C %

C ± 0.18 %

D

D ± 0.0018

10

1µF

C F

C %

C ± 0.21 %

D

D ± 0.0021

1

1

Z 

Z %

Z ± 0.40 %

± 0.23 °

100m

100m

Z 

Z %

Z ± 0.68 %

± 0.39 °

Measurement frequency 100kHz, Measurement signal level 1 Vrms, Cable length 0m

Measurement

range

Standard

(nominal

value)

Calibration value

of standard “A”

Measurement

value “B”

Difference

(ditto)

Specification

100k

100k

Z 

Z %

Z ± 1.2 %

θ °

± 0.67 °

10k

10k

Z 

Z %

Z ± 0.86 %

θ °

± 0.49 °

1k

Z 

Z %

Z ± 0.33 %

θ °

± 0.19 °

100k

10pF

C F

C %

C ± 1.4 %

D

D ± 0.014

10k

100pF

C F

C %

C ± 0.90 %

D

D ± 0.0090

1k

1000pF

C F

C %

C ± 0.35 %

D

D ± 0.0035

100

0.01µF

C F

C %

C ± 0.35 %

D

D ± 0.0035

10

0.1µF

C F

C %

C ± 0.55 %

D

D ± 0.0055

1

1µF

C F

C %

C ± 1.1 %

D

D ± 0.011

100m

100m

Z 

Z %

Z ± 3.5 %

± 2.0 °

For 1kΩ, 10kΩ, or 100kΩ range, use the standard resistor calibrated by 100kHz, if

available. Otherwise, use the standard capacitor. Use either one.
