3.2 Display at Power “ON” and Initial Setting
3-7 ZM2371/ZM2372
Table 3–1 Setting items and initial values 1/3
Setting items
Parameter range
Initial values
INIT
*RST
Setting
memory
Resume
<Measurement range
(including Rdc)>
Automatic selection
OFF(HOLD)|ON
ON
←
←


Range
100m to 1M
100
←
←


<Measurement signal>
Frequency
1m to 100kHz
1kHz
←
←


Measurement signal level
(voltage)
0.01 to 5Vrms
1Vrms
←
←


Constant voltage drive (CV)
OFF|ON
OFF
←
←


Minimum output impedance
5|25|100
25
←
←


Constant current level
1µ to 200mArms
1mArms
←
←


Constant current drive (CC)
OFF|ON
OFF
←
←


Internal DC bias voltage
0 to 2.50V
0V
←
←


Internal DC bias output
OFF|ON
OFF
←
←
×
×
Triggered drive
Continuous | Sync.
Continuous
←
←


<Measurement speed>
RAP|FAST|MED|SLOW
|VSLO
MED
←
←


<Trigger>
Trigger source
INT|MAN|EXT|BUS
INT (internal)
←
←


Trigger delay time
0 to 999.999 s
8ms
←
←


Continuous start
OFF|ON
ON
←
OFF
×
×
<Contact check>
(ZM2372 only)
Contact check
OFF|ON
OFF
←
←


Real time check
OFF|ON
ON
←
←


<Correction lower limit
frequency>
1m to 1kHz
40Hz
←
←


<SPOT correction>
OFF|ON
OFF
←
←


<OPEN correction>
ON/OFF
OFF|ON
OFF
←
←


Correction value (Primary &
Secondary parameters)
±9.99999E+11
Y conversion
(0, 0)
←
←


Format of correction value
G-B|Cp-G
G-B
←
←


<SHORT correction>
ON/OFF
OFF|ON
OFF
←
←


Correction value (Primary &
Secondary parameters)
±9.99999E+11
Z conversion
(0, 0)
←
←


Format of correction value
Rs-X|Ls-Rs
Rs-X
←
←


<LOAD correction>
ON/OFF
OFF|ON
OFF
←
←


Format of standard value /
correction value
Cp-D|Cs-D|Rp-Cp|
Rs-Ls|Rs-X|Z-
Rs-X
←
←


Correction value (Primary &
Secondary parameters)
±9.99999E+11
1, 0
←
←


Standard value (Primary &
Secondary parameters)
±9.99999E+11
1, 0
←
←


<Cable length>
0|1|2|4 m
0m
←
←


<Averaging>
ON/OFF
OFF|ON
OFF
←
←


Count
1 to 256
1
←
←


