Figure 79. General Mounting Dimensions
SlideSmart HD GENERAL PAD MOUNT DIMENSIONS
6.0”
(15 cm)
Gate
Chain, #40 Roller
Conduit Area
7 x 6”
(18 x 15 cm)
Conduit Area
7 x 6”
(18 x 15 cm)
Provisions for qty 4
1
/
2
” -13 X 3
1
/
2
” (M12 X 9 cm)
Concrete Anchors
(
1
/
2
inch (1.3 cm) slot in either direction)
NOTE: DRAWING IS NOT TO SCALE.
1.6” (4 cm)
2.0” (5 cm)
2.0” (5 cm)
Standard Batteries
Shown Installed
Chain Height
Pad 2.0” (5 cm)
Above Ground
Ground Level
Chain
3.25” (8.3 cm)
2.50” (6.4 cm)
Chain to Gate
3.13”
(8 cm)
1.0” (2.5 cm)
2.0”
(5 cm)
7.0”
(17.8 cm)
27.75”
(70.5 cm)
34.0”
(86.4 cm)
MIN. Pad Size
13.5”
(34.29 cm)
MIN. Pad Size
1.0” (2.5 cm)
ADJUSTABLE
8.0” (20 cm)
16.0” (41 cm)
Pad Size
APPENDIX A
-
INSTALLATION CONFIGURATIONS
