UNPACKING THE OPERATOR
Prepare the gate operator for installation. See Figure 7.
1. Open the top of the box and remove packing materials.
2. Cut open the box to access the operator.
3. Unlock the keyed latch and lift the cover up and off the base of the operator. DO NOT lift the cover
by its lock.
Figure 7. Unpacking the Operator
LATCH
COVER
POST
MOUNT
INSTALLATION
SlideSmart HD Programming and Operations
1919
MX4435 Rev.G ©2022
