This section provides information about the Smart DC Controller board; its inputs for peripheral
connections and its monitoring capabilities. This section explains how to:
1. Make connections on the Smart DC Controller
2. Connect Vehicle Detector
3. Connect Accessory Devices
• Entrapment Sensor Connections
• Access Controls
• Manual Push-button Station
• User Relays
Figure 50. Smart DC Control Box
SERVICE OUTLET
115 VAC, 15A
115 1Ø
USE ONLY COPPER
CONDUCTORS WITH
A TEMPERATURE RATING
OF AT LEAST 75 °C
FACTORY CONFIGURED
SMART DC CONTROLLER
SlideSmart HD Programming and Operations
