DISPLAY AND MENU OPTIONS
Table 10. Smart DC Controller - Installer Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC
Controller
Display
Connections
40
OLD 0 (RUN MODE)
OUT OBS LOOP SET
0 = Run mode
1 = Show frequency
2 = Show call level
0-7
3 = Set Frequency
Controls Hy5A or Hy5B Outside
Obstruction Loop detector. If an
Hy5B is used, additional settings
of 4-8 are available.
Hy5B
41
CLD 0 (RUN MODE)
CENTER LOOP SET
0 = Run mode
1 = Show frequency
2 = Show call level
0-7
3 = Set Frequency
Controls Hy5A or Hy5B Center
Loop (Shadow) detector. If an
Hy5B is used, additional settings
of 4-8.#22.
Hy5B
