DISPLAY AND MENU OPTIONS
This section of the manual provides information
about the display and menu options. It includes
how to:
1. Turn both AC and DC power switches on.
2. Review how to use the Smart DC Controller
Buttons in Menu Mode
3. Review Run Mode and Gate Status Displays
4. Access and Congure User Menu Options
• Adjust the Close Timer
• Set the Time and Date
• Set the AC Power Loss Gate Function
• Adjust the Display Contrast
5. Access and Congure Installer Menu Options
• Reset the OPEN & CLOSE Limits
• Set the Open and Close Gate Speed
• Adjust IES Sensitivity
• Enable Fire Department Access
• Reinstate Factory Defaults
INITIAL SETUP
Once you have completed the installation of
the SlideSmart operator and attached the wired
accessories, you’re ready to program the operator.
Two different approaches exist:
z Connect a laptop computer to the USB or serial
(RS-232) port and upload the gate settings and
set the operator menu congurations via the
START software.
z Manually navigate through the User and Installer
Menus using the ve buttons located under
the LCD display on the Smart Controller. The
instructions for performing this second option
are provided in this section.
NOTICE
Use a laptop computer at your place of
business to conveniently download the free
START software from www.hysecurity.com
before heading out into the eld. This makes
it easy to adjust settings using a laptop.
TURNING BOTH POWER SWITCHES ON
AC and DC power switches are located on the
outside edge of the control box. See Figure 30.
After "Programming the Initial Setup Menu"
on page 23, "Establishing the Open & Close
Limits" on page 25, "Installing the Target
Magnet" on page 26, and connecting to main
power (Power), take the following steps:
1. Turn both power switches ON. The gate
moves and searches for the target magnet to
re-establish the limits. An audible beep occurs
and a red light pulsates next to the OPEN
button on the Smart DC Controller which
indicates the system is functioning. If AC power
is lost, the rate of ashing slows down. Other
indicator lights are described below.
2. When the target magnet is detected, the
software version briey appears on the display,
and then one of the following modes appears:
z Gate status - indicates the operator is in Run
Mode. Refer to "Run Mode" on page 38.
z Alert, fault, and error messages - indicates
a problem exists with the operator which
needs to be resolved before the operator can
function properly. Refer to "Smart DC Controller
Troubleshooting" on page 92.
NOTICE
If the target magnet is not detected by the
operator, “ALERT 15 - NO TARGET” or
“LEARN OPEN” appears on the display. For
more information, refer to"Installing the Target
Magnet" on page 26.
SlideSmart HD Programming and Operations
3535
MX4435 Rev.G ©2022
