DISPLAY AND MENU OPTIONS
VIEWING OPERATOR STATUS DISPLAYS
Press the MENU button once and the operator status displays appear in two second intervals. Pertinent
information appears to provide a quick overview of the operator’s status or congurations. Refer to Table 7.
Table 7. Viewing Operator Status Displays
Display Variables Description
SOFTWARE VERSION
H5.##
Software version and revision number
are hard-coded in Smart DC Controller.
Displays software version when you
press RESET or cycle power. You will
need software version when calling
Technical Support.
DUAL GATE
<PRIMARY>
PRIMARY or SECONDARY
(Display only appears when operator
is used in dual gate systems.)
Indicates, in a dual gate setting,
whether operator is set to Primary
or Secondary. Setting is assigned in
Installer Menu.
OT <17>D
SLIDESMART HD25
OT 17 = SlideSmart HD
Indicates what type of operator the
board is programmed as.
<LEFT> HAND
LEFT or RIGHT
Designates which way a gate opens
viewed from operator. If it slides left,
it is a left-hand gate. Gate handing is
established in the initial Setup Menu.
UC <2>
USAGE CLASS
1, 2, 3, or 4
Displays operator’s Usage Class
designation per UL 325 standards.
Refer to Identifying Gate Operator
Category and Usage Class on page
16.
BT <0>
STANDARD BATTERY
0 = 8Ah (standard factory issue)
1 = 50Ah (optional upgrade)
2 = 110Ah (option)
Confirms operator’s battery
type. If you use larger capacity
batteries you must configure
operator through Installer Menu.
See BT - BATTERY TYPE.
D <32>.0 VDC
BATTERY VOLTAGE
Number varies depending on voltage
that charger is providing.
Displays actual charging voltage.
CC<002600>
CYCLE COUNT
One cycle equals a full open and close
sequence.
Displays number of cycles gate
operator has incurred. Similar to
an odometer, it resets to zero after
999,999 cycles.
CT 0 (OFF)
CLOSE TIMER
The rst menu item in the User Menu.
See "User Menu" on page 40.
NOTE: You can also access Installer
Menu from this display. See "Installer
Menu" on page 47. Displays
number of seconds before open gate
initiates
SlideSmart HD Programming and Operations
3939
