SMART DC CONTROLLER
All the control device inputs listed in Table 11 are shown as a single input. The second wire is connected
to a Common Terminal Bus (1 - 8) on the Smart DC Controller board.
The Fire Department Open input is an exception and requires a +24VDC input as well as enabling through
the Installer Menu. For convenience a +24VDC terminal is located next to the EMERG OPEN terminal.
See Figure 51. Note that programming in the User or Installer Menu is required for most connections.
Table 11. Smart DC Controller Board Inputs
Term.
No.
Label/Input Wire Connection Uses
1- 8
Common
Terminal
All user inputs are energized when connected to
common except Emergency Open. .
All inputs except
Emergency Open
9
Stop push
button*
Normally Closed (N.C.). input. Jumper to Common
if not being used.
Line of sight, external
stop button or 3-button
station.
10
Open push
button*
Normally Open (N.O.) input. Not for radio or remote
access controls.
Line of sight, external
open button or 3-button
station.
11 Close button N.O. input. Connection for a close push-button.
Line of sight, external
close button or 3-button
station.
12
Remote Open
& Radio
Control**
N.O. input. For radio/remote open device - Program
to also Close in User Menu (RO 1).
Remote access control
or radio controls
13 Partial Open
N.O. input. This input will cause the gate to open
to the Partial Open position programmed in the
Installer Menu (7-32ft).
Supervised access
controls
14 Sensor 2
N.C. input. Connection of a Monitored External
Entrapment sensor. Type of sensor used is
programmable in Installer Menu (S2).
External entrapment
sensors.
15 Sensor 3
N.C. input. Connection of a Monitored External
Entrapment sensor. Type of sensor used is
programmable in Installer Menu (S3).
External entrapment
sensors.
16
Free Exit Vehicle
Detector
N.O. input. Free Exit Vehicle Detector connection.
Vehicle detector, box
type connections for free
exit loop.
17
Block Free
Exit vehicle
detector or
Close Timer
N.O. input. Free Exit is only disabled if Close Limit
Switch is tripped. If the gate is partially opened, the
Free Exit detector will trigger the gate to open fully.
The input can be converted in the Installer Menu to
alternately disable the Close Timer.
If gate is partially
opened, Free Exit
detector will trigger gate
to open fully. Input can
be converted in Installer
Menu to alternately
disable Close Timer.
