SMART DC CONTROLLER
Table 13. User-Programmable User Relays - Function Options
No. Name Description
21
Inside Obstruction
Vehicle Detector
output
Active whenever Inside Obstruction Vehicle Detector is tripped
22
Center Loop Detector
output
Active whenever Center (Shadow) loop detector is tripped.
23
External Latching Gate
Lock Output
Not functional in SmartDC operators.
24
Gate at Partial Open
Position
Active when partial open position is reached or exceeded.
25 DC Power Alert
Active when on AC power or the battery voltage is above 21V. When
used with User Relay 2, this option can shed electrical loads to conserve
battery energy.
26
Free Exit Loop
Detector pulse
Outputs a 250ms pulse when the free exit vehicle detector is tripped.
27
Not Open (w/ AC
power)
Activated when gate is not on open limit and AC power is present.
Deactivated when AC power fails or gate is on open limit.
28 Flasher (w/ AC power)
Output identical to relay #19 and pulses relay 500 ms/sec when gate not
on open limit and AC power is present. Deactivated when AC power
fails or gate is on open limit.
29
Arm Entry Ticket
Dispenser
Not functional in SlideSmart operator.
30
Arm Exit Ticket
Dispenser
Not functional in SlideSmart operator.
31
Resert Ticket Dispenser
Pulse
Not functional in SlideSmart operator.
32 Backoff Pulse Not functional in SlideSmart operator.
33 Transient In Pulse Not functional in SlideSmart operator.
34 Transient Out Pulse Not functional in SlideSmart operator.
35 Tenant In Pulse Not functional in SlideSmart operator.
36 Tenant Out Pulse Not functional in SlideSmart operator.
37 Special In Pulse Not functional in SlideSmart operator.
38 Special Out Pulse Not functional in SlideSmart operator.
39 Unknown In Pulse Not functional in SlideSmart operator.
40 Unknown Out Pulse Not functional in SlideSmart operator.
41 Test Open Pulse
Output pulses ve seconds after close limit is activated. Typically used
for cycle testing.
42
Break-Away Switch
Output
Activates when arm break-away switch is tripped.
43 Warn Before Combination of relays #5 and #16.
SlideSmart HD Programming and Operations
