M2000 TS Description
1-6 Manual # 42-02-1P28 A3
HC-UIO-2 Universal Input/Output Board Depending upon the board configura-
tion, HC-UIO-2 boards may be used for programmable inputs and outputs (16 per board), car
and hall calls, and dispatching. In all cases, the functionality of the HC-UIO-2 board can be
expanded by plugging in additional boards. For more information see “HC-UIO-2 Universal
Input/Output Board” on page 6-18.
HC-DVR Driver Board The HC- DVR Driver board controls the starter and valves.
For more information see “HC-DVR Driver Board” on page 6-12.
Internal CAN connection
1 bus and 2 bus
24 - 120V AC or DC Inputs / Outputs
I/O Status Indicators
Board ID
Internal CAN connection
Starter, valve and hoistway limit connections
Indicators
