Complete the Installation and Field Wiring
Manual # 42-02-1P28 A3 3-21
Complete the Installation and Field Wiring
Refer to the job prints and complete the installation of equipment and field wiring to the con-
troller, including:
• Car Operating Panel (COP) switches and indicators
• Fire Service detectors and indicators
• Position indicators (A special interface board, MC-ZXFIX, allows Kinetek/ZXK position
indicators to be used with MCE controllers. If used, connection instructions are provided
in the prints for the job.)
• Hall switches and indicators
Check for shorts With the power turned OFF and prior to inserting the plug-in termi-
nals into the boards:
• Check all of the call and PI terminals for shorts to ground (1 bus).
• Check all of the call and PI terminals for shorts to the 2 bus.
Check with power ON With power turned ON at the main power disconnect:
• Jumper each of the call terminals, one-by-one, to ground (1 bus). Verify that no fuses blow,
especially F2, F2H and F2CC.
Plug in the terminal connectors With the power turned OFF at the main discon-
nect:
• Plug the call and PI terminal connectors into the PC boards.
Preparing the Car to Run on Test/Normal Mode
1. Verify that the HOISTWAY DOOR and CAR DOOR BYPASS switches work properly.
• Turn the switches ON. Verify that the indicators on the HC-CTL-2 board turn on and
that the car will run with doors open on Cartop and In-Car Inspections only.
• Turn the HOISTWAY DOOR and CAR DOOR BYPASS switches OFF. Verify that the
car will not run with doors open.
2. Verify that the door operator is operating properly with all door equipment (clutches,
rollers, etc.) properly adjusted with the correct running clearances and speeds.
3. Verify the door limits sequencing - DOL, DCL, DPM, DOLR, DCLR, and DPMR.
4. Make sure the car doors are closed and that all hoistway doors have been closed and
locked.
5. Ensure that the car gate and door locks are made. If there is rear door functionality, then
also ensure that the rear gate and door are made.
6. Run the car through the hoistway, on Cartop Inspection, to make sure that the hoistway
is completely clear.
7. Verify that the landing system has been installed according to the installation instruc-
tions. Check PI stepping, floor encoding, leveling and door zone.
8. Verify that the limit switches are operating properly.
9. Verify that the Access limit switches operate properly (car stops in the proper location).
10. Proceed to Section 4 Final Adjustment.
