M2000 TS Description
1-18 Manual # 42-02-1P28 A3
Attendant Mode
Attendant operation allows an operator riding in the car to run the car, choosing run direction,
and which hall calls to answer. In this mode:
• Doors open automatically when the car is stopped in a door zone.
• The attendant closes the door by pressing and holding the door close button, a car call but-
ton, or either car direction (UP/DOWN) button (ATS UP/ATS DOWN) input. The atten-
dant chooses the direction using run up (ATS UP) or down (ATS DOWN) buttons.
• The car will stop at the next car or hall call in the direction of travel. Holding the bypass
button (ATS input) in will cause hall calls to be bypassed until the button is released.
• The elevator will level into the destination floor automatically, then open its doors.
• In-car position indicators will light for floors at which there are active hall calls so that
they are visible to the attendant. The car will answer the calls unless the attendant is hold-
ing the bypass button (NSI).
• During Attendant operation, load weigher inputs are ignored.
Mode Entry
• Call the car to a floor.
• Enter the car and activate the Attendant mode key switch (enables the ATS ON, Attendant
Service, controller input).
Sabbath Mode
Sabbath operation is a special mode that sets the car to consecutively service specified landings
(and openings if the car has front and rear doors) during up and down travel with no hall or car
call buttons being pressed. The car will begin from the bottom of the hoistway, travel up and
stop at each designated landing and open its doors to allow exit or entry. When the doors close,
the car will travel to the next designated stop up the hoistway and repeat door operation. This
will continue until the car reaches the top designated stop, at which point it will travel down the
hoistway operating in the same manner.
• Go to CONFIG 01 > BUILDING SETUP > FLOOR ELIGIBILITIES to specify the floors (1-
16) to be automatically serviced during Sabbath operation. Specify Front/Rear openings
and Up/Down directions, via this parameter.
• Go to CONFIG 3 > ADDITIONAL FEATURES to configure the following Sabbath options:
•Enable
• Start Floor
• Return Floor Preferred
• Start Direction
•Number of Trips
• Pause Time
•Door Open Time
• Door Close Warning Buzzer
•Nudging
• Allow Hall Calls
• Allow Car Calls
