M2000 TS Description
1-16 Manual # 42-02-1P28 A3
Fire Recall Mode
Fire recall operation (Fire Phase I) recalls the elevator to a designated fire recall floor (main or
alternate) and removes it from passenger operation. Fire recall can be initiated by smoke detec-
tors or by a fire recall switch.
At the recall floor, the car will wait with doors closed or open (as configured). The car may enter
fire phase II operation automatically or by activation of a key switch inside the car
Emergency Medical Service Mode
This mode complies to Massachusetts code. It allows a car to be recalled to a floor where it can
be boarded by medical personnel and placed in restricted service, using an in-car switch, to
respond to a medical emergency.
Recall: Initiated using a key switch (EMSH SW input) at the floor assigned by the Massa-
chusetts EMS Floor parameter in the CONFIG 1 >BUILDING SETUP (single switch, single
floor).
The car will immediately cancel all registered calls, return to the designated floor, and
open its doors.
In-Car Medical: Medical personnel board the car and place it in hospital service using
the in-car switch (EMSC SW input).
If the hall switch has been shut off, the car will wait sixty seconds then return to nor-
mal service if the in-car switch has not been activated.
If the hall switch remains on, the car will wait without restriction until the in-car
switch is activated.
CFSS Recall Mode
Commandeer for Special Service - This mode can either be configured for Hospital Service or
VIP operation (See CONFIG 3 > CFSS for a full list of options). If the CFSS Medical Emergency
Option is set to YES, the car will be given a higher priority during Emergency Power Operation.
Each floor/side can be configured to call the elevator for a CFSS call. These calls will either be
on the 3rd IO of the serial HC-3HN hall call node board or stacked after the hall calls on an HC-
UIO board. CFSS Recall will take the car out of hall call service. The logic will read the user
configured CFSS Car Call Disposition to handle any existing car calls.
Cancel Calls: All car calls will be canceled, and car will immediately be sent to the recall
floor.
Answer Calls: The car will answer all car calls, but now allow new car calls. After all car
calls have been answered, the car will be sent to the recall floor.
Allow New Calls: The car will answer all car calls and allow new car calls. After all car
calls have been answered, the car will be sent to the recall floor.
Cancel at Next Stop: The car will stop at the next floor in the direction of travel and
open the doors. At this point all car calls will be canceled and a voice announcement can
tell passengers to exit the elevator. Once the doors close, the car will be sent to the recall
floor.
