Final Testing, LS-EDGE Only
Manual # 42-02-1P28 A3 4-13
To test the Normal Terminal Stopping Device
1. Remove the wires from terminals LIM2 and LIM3 on the HC-CTL2 board.
2. Apply 24VDC to the LIM2 and LIM3 terminals.
3. Under CONFIG 2 > HOISTWAY SETUP, note the Floor Step Up YY distance. Set it to
0 (zero) to disable it.
4. Make sure under CONFIG2 > NTS SWITCHES the USL/DSL 3 option is set to Virtual.
Move the car down and then make a call to the top landing.
5. Verify that the Fast Valves are disabled and car slows down near the top terminal floor.
6. Fault Up Terminal Limit Failure will be generated. Press Fault Reset button on
the HC-CTL-2 board to clear the fault.
7. Restore original settings.
Stop Ring Test
This procedure allows the car to be moved up against the stop ring for testing purposes.
1. Place the controller on Test Mode (TEST/PRETEST switch in the TEST position).
2. Register a car call to the top landing using the touchscreen.
3. Once the car arrives at the top landing, place the controller on Machine Room Inspec-
tion (MACHINE ROOM INSPECTION INSP/NORM switch in the INSP position).
4. Turn off test mode (TEST/PRETEST switch in the centered position).
5. Remove power to the controller at the main disconnect.
6. Disconnect the wire connected to the UNTD terminal on the HC-DVR board.
7. Place a jumper wire between the DNTD and UNTD terminals on the HC-DVR board.
8. Place a jumper wire between LIM0 and LIM3 terminals on the HC-CTL-2 board WITH-
OUT removing any preexisting wires on those terminals.
9. Restore Power to the controller at the main disconnect.
10. On the touchscreen, select CONFIG 02 > HOISTWAY SETUP > U/DTL LIMIT
OPT. If the value is not
PHYSICAL, record the value and change it to PHYSICAL.
Press SAVE on the touchscreen.
11. On the touchscreen, select CONFIG 02 > NTS SWITCHES > U/DSL OPTION. If
the value is not
DISABLED, record the value and change it to DISABLED. Press SAVE
on the touchscreen.
12. At this point the car may be moved up against the stop ring using the MACHINE ROOM
INSPECTION UP/DN switch for testing purposes.
13. Once the testing is completed, move the car back down to the top floor.
14. On the touchscreen, select CONFIG 02 > HOISTWAY SETUP > U/DTL LIMIT
OPT and change the value to the original setting.
15. Press SAVE on the touchscreen.
16. On the touchscreen, select CONFIG 02 > NTS SWITCHES > U/DSL OPTION and
change the value to the original setting. Press SAVE on the touchscreen.
17. Remove power to the controller at the main disconnect.
18. Remove the wire jumper between DNTD and UNTD and reconnect the disconnected
UNTD wire on the HC-DVR board.
19. Remove the wire jumper between LIM0 and LIM3 terminals on the HC-CTL-2 board.
