Final Adjustment
4-16 Manual # 42-02-1P28 A3
Release to Normal Operation
Final testing must be successfully completed before the car may be released for passenger oper-
ation.
Before the Elevator can be turned over to normal use, it is very important to verify that no
safety circuit is bypassed. The items to be checked, include, but are not limited to:
• Verify that the hierarchy of the inspection inputs is correct. Car top inspection must take
priority over in-car, hoistway access and machine room inspection modes. In-car must
take precedence over hoistway access and machine room inspection. Hoistway access
must take priority over machine room inspection.
• The FAULT jumper on the HC-CTL-2 board is removed (FLT bypass in C position).
• No jumper between terminals 2 and SAFH (HC-CTL-2).
• No jumper between terminals 2 and DLAB (HC-CTL-2).
• No jumper between terminals 2 and DLAT or DLMS (HC-CTL-2).
• No jumper across any of the limits (HC-DVR).
• No jumper between terminals SAFH and SAFC (HC-CTL-2).
• The Automatic Mode Fault Bypass option is set to BYPASS OFF.
