Specifications
Manual # 42-02-1P28 A3 1-19
• Finish Car Calls
• Car Call Lights
• Door Buttons
• Arrival Lanterns
• PI Outputs
• Override Security
• Initiate: Sabbath Operation is initiated when the spare input SAB is activated.
• Operation: In accordance with the description above and servicing stops set through the
Sabbath Operation parameter in the Additional Features menu (page 5-18).
Capture for Test (Pretest) Mode
When placed in Pretest mode, the car is taken out of hall call service and arrival annunciators
disabled. Remaining car calls will be served and new car calls may be placed but, when the car
completes servicing car calls, it will recall to the designated Capture floor or remain at the last
floor served; door action as programmed.
Capture operation is overridden by all modes except passenger operation.
Pretest is used to capture the car in preparation to using Test mode.
• When this input is activated, the car will stop responding to hall calls and disable its gongs
but continue to service car calls.
• The intent of the input is to allow maintenance personnel to capture the car while causing
as little disruption to service as possible.
• Enter Pretest mode by placing the TEST/NORMAL/PRETEST switch on the HC-CTL-2
board in the PRETEST position. (The car will not enter Pretest if Inspection is active.)
• A programmable recall floor for Capture mode is also provided.
Passenger (Automatic) Mode of Operation
Automatic operation is the normal, default elevator operating mode of operation and is active
so long as no other mode is selected. In this mode, cars accept hall calls and service car calls as
determined by several defined options. Please refer to User Interface starting on page 1-15.
Mode Entry
• Machine Room Inspection Mode Switch: Normal
•Test Switch: Normal
• Car Door Bypass: Off
• Hoistway Door Bypass: Off
Operational States
Unlike Operational Modes, the following operations are not mutually exclusive. The controller
may be in any one or more of these states. These states are only available during Automatic
Modes of Operation.
