Final Adjustment
4-2 Manual # 42-02-1P28 A3
Diagnostic Messages and Input/Output Signals
To speed up final adjustment and troubleshooting, become familiar with the Status and Error
Messages and Input/Output signals.
It will also be helpful to become familiar with the Motion 2000 TS Controller’s computer. See
The HC-MPU-2-TS Main Processor Unit on page 5-2 and Screen Descriptions on page 5-7.
On Board Diagnostics On all boards an ON LED provides the following diagnostic
information.
ON LED The ON LED reflects power/communications status.
•ON: Communications OK
• OFF: Board is not receiving power or has no software loaded.
• Blinking: Communications error - more than ten seconds have passed without a message
