Final Adjustments on Normal Operation
Manual # 42-02-1P28 A3 4-11
4
Remote Governor Testing (Roped Hydro)
For a roped hydro installation, the following procedure describes the remote testing procedure
for a Wittur Model OL35-NA governor.
Static Testing
Refer to the Operating Instructions supplied with the governor. Section 4 of these instructions
should be closely adhered to.
1. Locate the elevator controller slide switches labeled GOVERNOR TRIP #1, GOVERNOR
TRIP #2, GOVERNOR RESET #1, and GOVERNOR RESET #2.
2. Slide both switches GOVERNOR TRIP #1, GOVERNOR TRIP #2 from the OFF position
to TRIP position.
3. Observe that the safety circuit opens and the elevator will not move.
4. In order to return the system to normal operation, return both the GOVERNOR TRIP
slide switches to the OFF position and then move the slide switches labeled GOVER-
NOR RESET #1 and GOVERNOR RESET #2 from the OFF position to the RESET posi-
tion.
5. Finally move the slide switches GOVERNOR RESET #1 and GOVERNOR RESET #2
from the RESET position to the OFF position and observe that the safety circuit is now
made and elevator can operate normally.
Dynamic Testing
Refer to the Operating Instructions supplied with the governor. Section 4 of these instructions
should be closely adhered to.
1. Locate the elevator controller slide switches labeled GOVERNOR TRIP #1, GOVERNOR
TRIP #2, GOVERNOR RESET #1 and GOVERNOR RESET #2.
2. Move the elevator at contract speed in the down direction and simultaneously slide both
switches GOVERNOR TRIP #1 and GOVERNOR TRIP #2 from the OFF position to
TRIP position.
3. Observe that the safety circuit opens and the elevator stops and will not move.
4. In order to return the system to normal operation, return both the GOVERNOR TRIP
slide switches to the OFF position and then move the slide switches labeled GOVER-
NOR RESET #1 and GOVERNOR RESET #2 from the OFF position to the RESET posi-
tion.
5. Finally move the slide switches GOVERNOR RESET #1 and GOVERNOR RESET #2
from the RESET position to the OFF position and observe that the safety circuit is now
made and elevator can operate normally.
This completes testing of remote governor activation circuitry.
