Final Adjustment
4-4 Manual # 42-02-1P28 A3
CAR, MOTION, GROUP, PLD Diagnostics
These screens provide useful in depth diagnostics for the car and system control operations
(Car Operation, Car Motion Control Controller System, Group Control, and PLD). Flags are vis-
ible indicators of active signals, descriptively labeled so you can understand what they repre-
sent. Numerics are register data bit information and are intended for factory diagnostics. They
are also useful when MCE Technical Support is assisting in diagnosing a system.
The job prints will indicate what flags/functions are required to enable an output. The output
(or an input) can be viewed through the System I/O or System Diagnostics screen. Associated
flags/functions can be viewed through the screen for the appropriate safety processor or PLD.
CAR Diag Car Operation Control related indicators.
MOTION Diag Car Motion Control related indicators (valve enables, pump information,
limits, etc.).
GROUP Diag Communication and System Control related indicators.
PLD Diag System-wide PLD indicators.
Action Info
This display provides indicators that can help to discover why an unexpected action is occur-
ring.
Car Call Canceled Due To: Inputs or states that can cause car calls to be canceled.
Hall Call Canceled Due To: Inputs or states that can cause hall calls to be canceled.
Door Open Due To: Inputs or states that can cause doors to open or remain open.
Prohibit Run/Start Due to: Inputs or states that can cause starting or running to be dis-
abled.
Door Close Due To: Inputs or states that can cause doors to close or remain closed.
Status Info
View:
CPU, BUS, COM Status
CAN BUS Viewer: Internal CAN BUS diagnostics per CAN ID
Other Car Settings: See the other car’s parameters related to duplexing and Sabbath Oper-
ation
Monitoring Tools: Xport management for CHP board
Version Information: All software/firmware versions listed
Address Diagnostics: Processor diagnostics by address
