Startup - Inspection Operation
3-18 Manual # 42-02-1P28 A3
Hoistway Learn Operation
Hoistway Learn (Landing System Learn)
After installing the leveling and terminal magnets and setting step up/step down distances, you
will need to perform a learn operation to learn floor and switch positions. If floor level magnets
have not been positioned accurately enough, any offset can be adjusted in software (+/- 1 inch).
1. Place car on Test and Machine Room Inspection using switches on HC-CTL-2.
2. Set the FLT BYPASS jumper in the A position.
3. Select the UTILS menu. Select CONSTRUCT AND BYPASS FAULTS.
4. Select CONSTRUCTION FAULT BYPASS DISABLED; press OK to ENABLE. Press
EXIT. Faults are now bypassed.
5. Move car on inspection to about six or more inches above bottom terminal landing.
6. Select CONSTRUCT AND BYPASS FAULTS. Press CONSTRUCTION FAULT BYPASS
ENABLED. Press OK to disable fault bypass.
7. Move the FLT BYPASS jumper to the C position. Faults are no longer bypassed.
8. Select LANDING SYSTEM UTILITIES. Select HOISTWAY LEARN (LANDING SYSTEM
LEARN). Press LEARN.
9. Set Machine Room Inspection switch to NORM. The screen will display FINDING BOT-
TOM, followed by BOTTOM FOUND. The car will then begin to run up the hoistway.
During the run, the screen will display LEARNING. Once the top floor is learned the screen will
display FINALIZING, followed by STORING HOISTWAY, and finally DONE STORING HOIST-
WAY.
10. Press DONE. Press EXIT. Press EXIT on the following screens until the UTILS home
menu appears.
Construction Learn
The hoistway can be learned while on Construction using the MACHINE ROOM INSPECTION
switches if a problem is encountered using the normal learn procedure. When you select
LEARN, you are directed to move the car down to the bottom landing. Use the DN + ENABLE
switches. A message indicates when the bottom landing position is found. You are then
instructed to move the car up the hoistway as each landing is learned. Release UP + ENABLE
when CAR REACHED TOP is displayed. STORING HOISTWAY and finally DONE STORING
HOISTWAY are displayed.
Motion 2000 TS Hydro Adjustment
Perform a series of runs to various floors while observing the UTILS, Landing System View dis-
play to see that the car is stepping and leveling into each floor appropriately.
Adjusting Floor Heights
For the LS-EDGE landing system, floor heights are set during the hoistway learn operation, but
may be adjusted to compensate for floor level magnet position imperfections in CONFIG 02 >
HOISTWAY SETUP.
