Troubleshooting Reference
Manual # 42-02-1P28 A3 5-93
5
OIL TEMP: FIRE I (67) Description: Hydro Only. An over temperature oil condition has been
detected and the car is recalling on Fire Phase I. Car will lower to the bot-
tom landing or to the next lower floor. Doors will open then close within 15
seconds. Door open button will remain operative. Cannot be bypassed.
System Verifies:
- Oil Data, Recall Done is not True
- Recall Data = Recall Oil Temp
- Mode of Operation = Fire I
OIL TEMP: FIRE II (68) Description: Hydro Only. An over temperature oil condition has been
detected and the car is operating on in-car firefighter operation. Car will
operate per Elevator Safety Code. Cannot be bypassed.
System Verifies:
- Oil Data, Recall Done is not True
- Oil Data = Oil Fire Recall
- Recall Data = Recall Oil Temp
- Mode of Operation = Fire II
OIL TEMP: ON (111) Description: Hydro Only. The oil (over) temperature input is active. Car
will lower to the bottom landing, open its doors, and shut down. Manual
reset required. Cannot be bypassed.
System Verifies:
- Oil Data =Oil Temp Recall and Oil Fire Recall are not true
- Oil Temp input true
OIL TEMP: RECALL (66) Description: Hydro Only. Oil over temperature detected. Car will lower to
bottom landing, doors will open. Doors will close within 15 seconds. DOB
will remain active. Cannot be bypassed. Manual reset required.
System Verifies: - Oil Data = Oil Temp Recall
OIL TEMP: RECALL FAIL (70) Description: Hydro Only. An over temperature oil condition has been
detected and the car is unable to recall. Cannot be bypassed.
System Verifies:
- Oil Data = Oil Recall Fail
- Recall Data = Recall Oil Temp
OIL TEMP: SHUTDOWN (69) Description: Hydro Only. Oil temperature recall is complete. Cannot be
bypassed.
System Verifies:
- Oil Data = Recall Done
- Recall Data = Recall Oil Temp
OIL VISCOSITY (101) Description: Hydro Only. If a temperature sensor determines the oil is too
cold and no calls are registered, the car will move to the bottom landing
(doors closed) and the pump motor will run without valve coils energized to
circulate and heat the oil. Fault-bypassed in Construction.
System Verifies:
- Oil Data = Oil VCI Recall
- Oil Data = Recall Done
- Recall Data = Recall Oil VCI
Table 5.10 Touch Screen Event Listings
Event Description
