Troubleshooting Reference
Manual # 42-02-1P28 A3 5-95
PAUSED. . . (819) Description: The event is logged during Sabbath operation in between
trips (if enabled) when the car has served the building a number of times
(as configured). This event is not logged and is only displayed on the LCD
HOME screen (to avoid filling the log with this event).
Car actions: Sabbath operation has been paused and the car will no lon-
ger automatically serve the building while paused. Sabbath operation will
resume when the corresponding timer has elapsed.
Troubleshooting:
1. Check and set the SABBATH: # OF TRIPS option as desired.
2. Check and set the SABBATH: PAUSE TIME option as desired.
PHE ANTINUIS. DISABLED (250) Description: Informational. PHE anti-nuisance has been disabled.
PHE ANTINUISANCE (249) Description: Informational. The photo eye anti-nuisance call threshold has
been achieved; all car calls are canceled. Self resetting. Cannot be
bypassed.
PHE2 BYPASS FRONT (838)
PHE2 BYPASS REAR (841)
Description:
The auxiliary (front/rear) photo-eye device (required for Peelle doors for
PHE integrity tests has been continuously activated for a user-defined time
and is now bypassed in accordance with the related user-defined settings.
Car actions:
The auxiliary photo-eye device is rendered inoperative, and doors are
closed. Doors close at reduced speed if not other reopening devices are
available.
Troubleshooting:
1. Check the auxiliary photo-eye input and related circuitry.
2. Check the related used defined option to bypass the photo eye.
3. Check the related stuck photo eye user defined timer.
4. Fault is cleared when the auxiliary photo-eye input is deactivated.
PHE BYPASS FRONT (31)
PHE BYPASS REAR (776)
Description: The door photo eye/infrared detector has been active for a
timer determined period and is now being bypassed. Fault-bypassed in
Construction.
System Verifies: - Door Flags = Photo Eye Bypassed
Troubleshooting:
If in error, verify no input programmed PHE.
Check the PHE input.
See related Stuck PHE and Bypass Stuck PHE events.
PHE FAIL FRONT (32)
PHE FAIL REAR (777)
Description: The door photo eye/infrared detector has failed. Issued when
the photo eye has been continuously activated for a predetermined time
while the doors are fully closed. Fault-bypassed in Construction.
System Verifies:
- Door Flags = Photo Eye Failed
Troubleshooting:
If in error, verify no input programmed if PHE not used.
Check that input is properly wired and programmed.
System IO > Programmed Inputs > PHE.
Table 5.10 Touch Screen Event Listings
Event Description
